Product Details
Place of Origin: China
Brand Name: INFINITE STARS
Certification: CE/ISO9001/ISO45001/ISO14001
Model Number: H
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 7 Sets
Packaging Details: One 40 'high container for Marine insurance, can hold 6 sets
Payment Terms: L/C, T/T
Supply Ability: 20000 Set PER Month
|
Name:
|
Flat Pack Container House
|
Fire Proof:
|
A Grade
|
Steel Grade:
|
Q235B Or Q345B
|
Customization:
|
Available
|
Life Span:
|
20 Years
|
Window Size:
|
950 Mm*1200 Mm
|
Certificates:
|
ISO & CE
|
Design:
|
Modern
|
Steel Door:
|
Red, Green, Blue, White, Optional
|
Main Materia:
|
Light Steel Frame & Sandwich Panel
|
Size:
|
20ft, 40ft
|
Hs Code:
|
9406900090
|
Installation:
|
Easy And Quick
|
Earthquake Resistance:
|
7 Magnitude
|
Length:
|
6050mm
|
MOQ:
|
7 PCS
|
|
Name:
|
Flat Pack Container House
|
|
Fire Proof:
|
A Grade
|
|
Steel Grade:
|
Q235B Or Q345B
|
|
Customization:
|
Available
|
|
Life Span:
|
20 Years
|
|
Window Size:
|
950 Mm*1200 Mm
|
|
Certificates:
|
ISO & CE
|
|
Design:
|
Modern
|
|
Steel Door:
|
Red, Green, Blue, White, Optional
|
|
Main Materia:
|
Light Steel Frame & Sandwich Panel
|
|
Size:
|
20ft, 40ft
|
|
Hs Code:
|
9406900090
|
|
Installation:
|
Easy And Quick
|
|
Earthquake Resistance:
|
7 Magnitude
|
|
Length:
|
6050mm
|
|
MOQ:
|
7 PCS
|
Packaged Container Houses With A Prefabricated Top And Bottom That Can Be Built Quickly Are Affordable
| Standard Package Container House Datasheet | ||||||||||
| Product Specification: 2.99-meter standard container |
Length(mm) | 6055(5840) | ||||||||
| Width(mm) | 2430(2270) | |||||||||
| Height(mm) | 2896(2550) | |||||||||
| Roof | organized drainage | |||||||||
| Number of floors | ≤3 | |||||||||
| Design parameters | Service life | 8-10 years | ||||||||
| Container weight | ≤1.96T | |||||||||
| Ground live load | 1.8KN/㎡ | |||||||||
| Roof live load | 1.0KN/㎡ | |||||||||
| Wind load | 0.8KN/㎡ | |||||||||
| Seismic degree | 8 | |||||||||
| Structural | corner column | Galvanized cold rolled section steel, t=2.5mm, H2450X4 pcs material Q235B | ||||||||
| roof main beam | Galvanized cold rolled section steel, t=2.5mm, L5630X2pcs /L2130X2pcs material Q235B | |||||||||
| roof sub-beam | Galvanized square steel, t=1.8mm40*60X6 square tubes, radian t=1.8mm 15*30X3pcs square tube material Q235B | |||||||||
| floor main beam | Galvanized cold rolled section steel, t=2.5mm, L5630X2pcs /L2130X2pcs, material Q235B | |||||||||
| floor sub-beam | Galvanized square steel t=1.2mm, sub-beam X9pcs square tube material Q235B | |||||||||
| Angle piece hanging head | 4.2mm steel galvanized stamping welding built-in bucket Angle piece X8 | |||||||||
| Paint | Graphene Powder spraying (Electrostatic spraying) | |||||||||
| Roof | Roof panel | 0.5mm thick color steel plate 360 degree bite, color white gray | ||||||||
| Thermal insulation | 100mm glass thermal insulation foam | |||||||||
| Ceiling plate | 0.38 thick 831 ceiling | |||||||||
| downpipe | Four corners of downpipe 50PVC pipe X4pcs | |||||||||
| Floor | Base | 18mm thick fiber cement pressure plate, density ≥0.8g/cm³ | ||||||||
| Wall | Thickness | 50mm thick color steel rock wool sandwich board; The outer and inner plates are made of 0.35mm galvanized color steel plate | ||||||||
| Heat preservation | 75mm thick rock wool, bulk weight ≥90kg/m³, combustion performance is class A non-combustible | |||||||||
| Color | white gray PE coating | |||||||||
| Door | Spec(mm) | Width X height =840*2035 high-end door | ||||||||
| Material | Steel door with paint | |||||||||
| Window | Spec(mm) | Front window: width X height =1150*1100: width X height =1150*1100; (Standard) Hollow window anti-theft integrated window | ||||||||
| Frame | Plastic-steel | |||||||||
| Glass | single | |||||||||
In today's fast-paced world, we understand the need for a cost-effective yet durable housing solution that can be quickly assembled and dismantled. Our prefabricated container houses are designed to meet these demands, offering a practical and economical choice for a wide range of applications.
Key Features:
Applications:
Our prefabricated container houses are suitable for a wide range of applications, including:
